Genie

Genie TorqueMaster Adapter Kit for Wall Mount Operator

SKU:
41032R
MSRP: $262.84
$238.95
(You save $23.89 )
  • Usually Ships Following Business Day
availability:
available
Adding to cart… The item has been added
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Genie TorqueMaster Adapter Kit for 6070H & 6170H-B Operators
Upgrade your garage door system with the Genie TorqueMaster Adapter Kit, the first and only approved solution for connecting Genie’s 6070H and 6170H-B wall mount operators to Wayne Dalton’s TorqueMaster spring system.

This easy-to-install kit features a split sprocket design, eliminating the need to disassemble the system for installation. The adapter provides flexible mounting options—supporting both left- and right-hand side installation, making it ideal for a wide range of residential setups.

Whether you're retrofitting or upgrading, the Genie TorqueMaster Adapter Kit provides a secure, efficient connection between modern operator technology and TorqueMaster hardware.


Product Features:

  • Compatible with Genie 6070H and 6170H-B wall mount garage door operators

  • Enables use with Wayne Dalton TorqueMaster spring systems

  • Split sprocket assembly allows for easy installation—no disassembly required

  • Can be mounted on either side of the operator for greater flexibility


Clearance Requirements:

  • 6 inches of extra headroom above the ratchet bracket

  • 10.5 inches of side room from the ratchet bracket to the side wall


Recommended Tools for Installation:

  • 7/16" and 9/16" socket and/or wrench

  • 1/4" socket, wrench, or nut driver

  • Drill with 3/32" and 3/16" pilot hole bits

  • 3/32" common screwdriver

  • 7/64" and 5/32" Allen wrenches
