EMX ULT-MVP-2 Ultra-Mini-Voltage Loop Detector

The ULTRA-MVP-2 Two Channel Multi-Voltage Vehicle Loop Detector (EMX-2630-1) is designed for advanced vehicle detection in access control systems requiring directional logic and dual loop monitoring. With a wide input range of 12VDC to 240VAC, this detector allows a single unit to be used across multiple installations, helping reduce inventory requirements.

This model features DETECT-ON-STOP™ (DOS) technology, enabling detection only when a vehicle comes to a complete stop. This function is especially useful in tight spaces where cross traffic could otherwise cause false activations. The compact housing and built-in diagnostics make it suitable for installations where space and performance visibility are critical.

Key Features

• Dual channel design with independent loop monitoring
• Universal power input: 12VDC to 240VAC
• DETECT-ON-STOP™ for stop-only vehicle detection
• AB logic (directional mode) for traffic flow control
• ULTRAMETER™ display for sensitivity and interference diagnostics
• 10 adjustable sensitivity levels (0–9)
• 4 selectable loop frequencies to reduce crosstalk and interference
• Configurable modes: fail-safe/fail-secure, delay, and presence settings

Electrical & Output Specifications

• Two SPST relays (form A), one per channel
• Contact rating: 2A @ 30VDC, 0.5A @ 125VAC
• Operating current: 37mA standby, 55mA during detection
• Power consumption: up to 1.0 VA (DC) / 2 VA (AC)
• Red LED indicators for channel detection and diagnostics
• Integrated surge suppression for loop protection

Loop & Physical Specifications

• Loop inductance range: 20–1000 µH (Q-factor > 5)
• Automatic tuning on power-up with environmental tracking
• Isolation transformer supports operation with poor-quality loops
• Operating temperature: -40°F to 180°F with up to 95% humidity
• Compact size: 2.9” L x 1.2” W x 3.1” H
• ABS plastic housing rated IP30
• Socket mount: 11-pin male (JEDEC B11-88)

The ULTRA-MVP-2 loop detector is well-suited for applications requiring dual loop inputs and directional detection logic. Its combination of compact size, multi-voltage compatibility, and advanced diagnostic features supports reliable performance in both new installations and system upgrades.
