EMX LRS-FP-100 Sensor - Flat Pack with 100ft Lead

The EMX LRS-FP-100 Flat Pack Direct Burial Sensor is a magnetoresistive vehicle detection solution designed for in-ground installation in pavement. Featuring a 100-foot lead wire and compact profile, this sensor is engineered for accurate detection of vehicles by measuring disturbances in the Earth’s magnetic field.

Designed for use with the EMX LRS-C1 control unit, this sensor stores configuration settings in non-volatile memory, allowing it to operate independently after setup. Its flat pack design enables single-cut installation, reducing labor and material costs compared to traditional inductive loops.

Key Features

• Magnetoresistive sensor with 100' lead wire
• Detects vehicles by measuring changes in Earth's magnetic field
• Three-axis sensing (X, Y, Z) for improved detection accuracy
• Detect-On-Stop (DOS) feature for stop-only vehicle detection
• Designed to reduce false triggers in high-traffic areas
• Non-volatile memory stores settings after programming
• Fast response time for high-speed detection applications
• Direct burial design for below-grade installation only

Electrical & Performance Specifications

• Power supply: 12–30 VDC
• Current draw: 10 mA maximum
• Output: NPN (open collector)
• Output rating: 50 mA
• Sensing range: up to 5 feet in all directions

Physical Specifications

• Dimensions: 3.0" x 0.8" x 0.35"
• Weight: 0.05 lbs
• Housing: Polyolefin
• Environmental rating: IP69K

Applications

• Boom gate and access control systems
• Drive-thru and car wash vehicle detection
• Loading dock and truck detection
• Parking, toll booth, and vehicle counting systems
• Industrial gate and door automation

The EMX LRS-FP-100 direct burial sensor is a compact and efficient alternative to inductive loop systems. Its precise detection capabilities, reduced installation requirements, and durable construction make it well-suited for commercial and industrial vehicle detection applications.
