LiftMaster AUXCARD Auxiliary Contacts Option Board

SKU:: AUXCARD

MSRP: $71.69

$65.17

(You Save $6.52)

Add accessories to commercial door opener and remotely activate relays for them
Usually Ships Following Business Day

Current Stock:

Quantity:

Adding to cart… The item has been added

UPC:
brand-name:: LiftMaster
brand-url:: /brand/liftmaster/
availability:: available

Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Product Description
Related Products
Product Manual

Enhance the versatility of your commercial garage door systems with the LiftMaster AUXCARD Auxiliary Contacts Option Board. This printed circuit board integrates directly with LiftMaster Logic 4 and Logic 5 commercial door operators to provide additional relay contact options for powering external accessories.

Whether you're incorporating lights, alarms, or other auxiliary systems, the LiftMaster AUXCARD offers flexible functionality through both normally open (NO) and normally closed (NC) contacts. It enables on/off control of accessories via relay functions—ideal for facilities requiring complex automation setups.

Please note: when used with NEMA 4 or NEMA 4X rated devices, remote relay control is not supported. An external power source is required for operating any connected accessory, with wiring using #14 AWG copper wire recommended.

Key Features:

Product Name: LiftMaster AUXCARD Auxiliary Contacts Option Board
Designed for use with Logic 4 and Logic 5 LiftMaster Commercial Door Operators
Adds support for external accessory integration via auxiliary relays
Direct plug-in installation onto motherboard card interface
Provides NO (Normally Open) and NC (Normally Closed) contact types
External power source required for connected accessories
Contact rating: 10A at 240 VAC (not rated for incandescent loads)
Wiring: Use #14 AWG copper wire
Includes remote ON/OFF relay control (except NEMA 4/NEMA 4X)

Relay Operation Details:

Status	Relay Behavior
Operator powered down	Close 2-1 Closed, 2-3 Closed
Operator in motion	Open 2-1 Open, 2-3 Closed
While closing	Open 2-1 Closed, 2-3 Open
While opening	Close 2-1 Closed, 2-3 Open
NEMA 4/NEMA 4X – closing/opening	Open terminals unavailable
