LASER SCANNER FOR GATE & BARRIER APPLICATIONS

The BEA LZR-H100 Laser Scanner is a cost-effective, no-cut alternative to induction loops for gates and barriers. This time-of-flight sensor installs in just 1–2 hours, eliminating the need to cut pavement and avoiding long cure times. Its laser-based technology delivers precise, 3D motion and presence detection, filtering out pedestrian traffic while covering areas up to 32 ft x 32 ft.

Compatible with DC power only, the LZR-H100 mounts 16 inches above ground and includes two relays for activating gates, barriers, access devices, or warning signals. BEA's 10REMOTE Universal Remote (sold separately) is required for full adjustment of the sensor’s detection range.

Product Highlights:

• Part Number: LZR-H100

• Quick installation — no cutting or curing required

• 4 laser curtains for 3D motion and presence detection

• Filters out pedestrians; ideal for gates and barriers

• Max detection area: 32 ft x 32 ft

• NEMA 4/IP65 rated for durability

• DC supply voltage: 10–35 VDC

Kit Includes:

• LZR-H100 sensor

• Hex key, 30 ft cable, screw pack, adjustable bracket

• Mounting template, reference point sticker, user guide

Dimensions:

• Width: 3-5/8 in

• Height: 2-3/4 in

• Depth: 5 in
