• Usually Ships 4 to 7 Business Days
  • MSRP: $2,736.24
    $2,487.49
    (You save $248.75 )
USAutomatic

Patriot RSL - AC or SOLAR Charged Slide Gate Operator w/LCR Radio Controls - by USAutomatic

SKU:
PATRIOT-RSL
MSRP: $2,736.24
$2,487.49
(You save $248.75 )
  • Usually Ships 4 to 7 Business Days
availability:
available
Adding to cart… The item has been added
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

USAutomatic Patriot RSL Slide Gate Operator – AC or Solar Powered with LCR Radio Controls

The USAutomatic Patriot RSL is a high-performance slide gate operator designed for residential, light commercial, farm, and ranch use. Engineered to handle gates up to 32 feet long and 600 lbs, it’s ideal for properties needing reliable, solar-ready automation or full system backup during AC power outages.

The Patriot RSL offers pad or post mount flexibility, a manual release knob for emergency access, and adjustable limit switches for precise operation. With Photo Eye Power Management (PEPM), any photo eye sensor can be used—no extra solar panels needed. Whether AC or solar powered, this gate operator uses a smart controller designed for maximum energy efficiency.

Choose from:

  • 020410 – AC Charged Patriot RSL Slide Gate Operator

  • 020430 – Solar Charged Patriot RSL Slide Gate Operator

Key Features:

  • Handles slide gates up to 32 ft and 600 lbs

  • Pad or post mounting options included

  • Compatible with Class I–IV vehicular gates (UL 325 compliant)

  • Thompson gear motor with built-in brake for smooth operation

  • Built-in close timer, soft stop feature, and dual gate sensitivity adjustments

  • PEPM technology enables use of any photo eye sensor without added solar needs

  • Heavy-duty ABS molded housing for durability in all environments

  • Manual release knob for quick disengagement

  • AC or solar charging options available with built-in smart controller

  • Battery-powered system provides real backup (not just one cycle)

  • Compatible with solar-friendly accessories

  • Pre-wired dual channel LCR radio receiver included

What’s Included:

  • Operator Frame, Cover, and Control Board

  • Emergency Manual Release Cover

  • AC Transformer or Solar Kit (model dependent)

  • Smart Battery Charger or Solar Controller

  • 2-Button Transmitters (x2)

  • Charge Control Harness

  • LCR Radio Receiver with Harness

  • Antenna and Mounting Bracket

  • Safety Warning Signs

Note: Requires 12V sealed battery, 30Ah minimum (not included). For areas with frequent outages or limited sunlight, consider a 70Ah battery.
