TRANSMITTER SOLUTIONS TX-100 REIGN LONG RANGE TRANSMITTER

The Transmitter Solutions TX-100 REIGN Long-Range Transmitter is a powerful, single-button remote control designed for extreme distance access applications, including gates, garage doors, aviation hangars, agricultural sites, and industrial facilities. Built for use with the XRE-100 REIGN long-range receiver or as part of the REIGN Extreme Long-Range Operator Kit, this transmitter ensures maximum control range and secure operation even in challenging environments.

Using AES128 encrypted binary frequency protocol, the TX-100 REIGN delivers secure, interference-resistant communication at distances of up to 1,000 feet through ground-level obstructions and a half-mile line-of-sight range. A twist-knob range adjustment dial allows you to fine-tune the broadcast range—perfect for applications with multiple REIGN transmitters in close proximity.

Key Features:

• Model: TX-100 REIGN

• Compatibility:

  • Works with XRE-100 REIGN Receiver

  • Add-on for REIGN Extreme Long-Range Transmitter Kits

• Frequency Protocol: AES128 encrypted binary protocol

• Range:

  • Up to 0.5 miles line-of-sight

  • Up to 1,000 ft through typical obstructions

• Transmitter Type: Single-button remote with removable visor clip

• Security: Advanced encryption for high-security applications

• Programming: DIP-switch configurable

• Battery: 9V rechargeable battery (included)

• LED Indicators:

  • Red: Signal being sent

  • Green: Signal received

• Temperature Rating:

  • Minimum: -40°F (-40°C)

  • Maximum: 185°F (85°C)

• Dimensions:

  • Height: 3.5 in

  • Width: 2.375 in

  • Depth: 0.75 in

  • Compact rectangular body with rounded edges

Applications:

• Commercial gate access systems

• Aviation and hangar doors

• Agricultural and rural properties

• Institutional access control

• Long-range garage door operation

Benefits:

• Extreme distance performance for large-scale properties

• Secure signal transmission using AES128 encryption

• Customizable range for installations with multiple transmitters

• Simple, durable design for reliable daily use in harsh conditions

The TX-100 REIGN Long-Range Transmitter is the go-to solution for operators requiring extended wireless range, modern encryption, and rugged reliability. It’s ideal for professionals managing large entry points or facilities needing dependable remote access from afar.
