Door Controls USA
Swing Door Operator - DC7000 Low Energy ADA Compliant
MSRP:
$1,309.53 - $2,619.04
$1,190.48 - $2,380.95
- Usually Ships 4 to 7 Business Days
Door Controls USA DC7000 ADA-Compliant Low Energy Door System
The DC7000 low energy door system from Door Controls USA provides safe, code-compliant accessibility for commercial and institutional entryways. Built for both new construction and retrofit projects, it delivers reliable performance, touchless activation compatibility, and ADA compliance for barrier-free access.
Key Features
- Multi-Industry Use: Ideal for hospitals, assisted living facilities, schools, universities, banks, libraries, retail, and hospitality settings.
- ADA & ANSI Compliant: Meets ANSI A156.19, A117.1, and ADA (1990) standards to ensure accessibility and safety.
- Flexible Mounting: Quick installation on both new frames and existing structures.
- Touchless Ready: Works with wave-to-open sensors and other hands-free activation options for improved hygiene.
- Door Compatibility: Supports butt-hinged and center-pivoted door configurations.
- Fire & Life Safety: Approved for use in compliance with fire and building codes.
Specifications
- Maximum Door Widths: Single units: 3'–3'6" (0.914m–1.067m); Pair units: 5'–7' (1.524m–2.133m)
- Door Weight Capacity: Up to 200 lbs (91 kg) per panel
- Electrical Requirements: 120/220 VAC, 50–60 Hz, single phase; 15A service, 3.15A draw
- Time Delay Adjustment: 2–30 seconds, with a minimum 5-second delay per ANSI A156.19
Available Options
- Arm Style: Push, Pull, or Push-Pull (double egress)
- Door Types: Single, Pair, or Double Egress
- Handing: Left or Right
- Finishes: Clear Anodized or Dark Bronze Anodized
The DC7000 provides a dependable solution for enhancing accessibility, meeting safety codes, and delivering long-term durability in high-traffic environments.
