Janus International Pantheon Logic Controller Pantheon-LC

Janus Pantheon Logic Controller – Low Voltage DC Control Box

The PANTHEON-LC is a low-voltage DC logic control box designed exclusively for use with the Janus Pantheon Rolling Steel Door Operator. Engineered for commercial and industrial environments, the unit combines electronic safety features, soft start/stop motion control, and plug-and-play wiring to simplify installation and operation.

Users can select between two model variants at the time of order:

• Mini Controller – Part Number: 700005-0000

• Commercial Controller – Part Number: 700006-0000

Key Features

• Electronic Limit Setting
  No cams or mechanical switches—travel limits are configured using a learn button and retained through power interruptions.

• Soft Start + Stop Software
  Reduces motor stress at the beginning and end of each cycle, enhancing door longevity and detecting obstructions.

• Auto Close Function
  Programmable delay options: 10, 20, 40, or 60 seconds.

• Auto-Reversing Feature
  Detects contact during closure and reverses direction when properly configured with adjustable electronic sensitivity.

• Diagnostic Fault System
  Audible beeps indicate system status and errors for faster troubleshooting.

• Flush-Mounted Controls
  Integrated Up, Down, and Stop buttons on the panel surface.

Advanced Circuit Board Design

• Clearly Labeled Plug-In Terminals
  Simplifies connections for accessories like safety eyes, receivers, and external timers.

• Supports 12V or 24V DC accessories

• Potentiometers for adjusting sensitivity

• Fuse-protected main power (110V AC)

• Isolation switch for safe installation and maintenance

• Compatible with left-hand or right-hand mountings (specify when ordering)

Wiring & Accessory Support

• Receiver input terminals (12/24V DC)

• Photoelectric sensor terminal

• External timer terminal (for 24-hour or 7-day timers)

• Safety eye input with fail-safe behavior

• No soldering or hardwiring required—just plug, terminate, and secure

Specifications

• Part Number: PANTHEON-LC

• Width: 8.5 inches

• Height: 12 inches

• Power Input: 110V AC (fuse protected)

• Device Power Output: 12V or 24V DC

• Mounting: Left-hand or right-hand configurable

Applications

• Rolling steel doors

• Commercial and industrial overhead doors

• Retrofit and new installations using Janus Pantheon operators
