CHATEAU C-485 BEZEL LATCH FOR MINI WAREHOUSE ROUND CORRUGATED DOORS

C-485-BK-SGL 2-Bolt Bezel Latch – Zinc-Plated for Corrugated Doors

The C-485-BK-SGL 2-Bolt Bezel Latch is a flush-mount, zinc-plated latch designed for compatibility with a range of corrugated roll-up doors, including Roll-Lite, Roll-Right, PILOT, Trac-Rite, Wayne-Dalton, and EPIC models. The corrosion-resistant finish ensures long-lasting performance, especially in indoor or sheltered environments.

This latch features a built-in slot for long milled cylinder locks and is sold non-bolted, allowing users to pair it with their preferred locking cylinder based on their specific security needs.

Key Features

• Part Number: C-485-BK-SGL

• Finish: Zinc plated to resist rust and corrosion

• Mounting Style: Flush-mount installation

• Lock Slot: Accepts long milled cylinder locks

• Latch Type: Non-bolted, 2-bolt bezel design

• Compatible With:

  • Roll-Lite

  • Roll-Right

  • PILOT

  • Trac-Rite

  • Wayne-Dalton

  • EPIC corrugated doors

Dimensions

• Latch Body:

  • Length: 9-3/4"

  • Width: 2-3/4"

• Lock Hole:

  • Outside Diameter: 1-1/16"

  • Inside Diameter: 7/8"

• Mounting Hole Distance: 6.5" (center to center)

• Mounting Bracket:

  • Length: 7-3/4"

  • Width: 1-1/8"

  • Depth: 1/16"

Compatible Locking Cylinders (Sold Separately)

• C-480-EZ-S-CD-KD – EZ short milled cylinder, keyed differently

• C-480-S-CD-KD – Short milled solid brass cylinder, lifetime warranty

• C-480-CD-KD1 – Maximum security red line cylinder lock

This latch is ideal for self-storage facilities, mini warehouses, and any application requiring a reliable, retrofit-compatible lock solution for corrugated doors.
