BEA 300 MHz 1-Button Hand-Held Wireless Transmitter 10T300HH

The BEA 10T300HH is a 300 MHz hand-held analog transmitter with a single button, designed for reliable wireless activation of automatic doors. Part of BEA’s 300 MHz analog radio control series, it is universally compatible with any automatic door system and comes with a protective case and clip for convenience.

Supporting up to seven transmitters per receiver, the 10T300HH delivers strong, short-range analog transmissions and is easy to set up. Flag connectors allow it to plug directly into most BEA push plate switches, while DIP switch programming provides up to 1,024 unique identifier codes for secure and flexible operation.

Product Highlights:

• Item Number: 10T300HH

• 300 MHz hand-held analog transmitter

• Single-button design controls one receiver

• Includes protective case and clip

• Universally compatible with all automatic door applications

• Supports up to seven transmitters per receiver

• Easy installation with flag connectors and DIP switch setup

• Up to 1,024 unique identifier codes

• Strong, short-range analog signal

Technical Information:

• Frequency: 300 MHz

• Radio Control Type: Analog

• Input Voltage: 24V AC/DC

• Operating Temperature: +14°F to +131°F (–10°C to 55°C)

• Setup: 10-position DIP switch

• Power:

  • Hardwired: 9V or 12V battery

  • Wireless: 9V or 12V battery

• Maximum Transmitters Per Receiver: 7

• Certifications: CE, FCC, IC

Receiver Dimensions (for reference):

• Without Flange: 4.9” × 3.2” × 1.4”

• With Flange: 5.4” × 3.2” × 1.4”
