BEA 433 MHz Frequency Digital Receiver 10RD433

The BEA 10RD433 433 MHz Digital Receiver is a compact, versatile wireless receiver designed for use with BEA’s Panther Series of wireless push plates. Featuring integral sequencing “learn” buttons, this receiver is perfect for vestibule sequencing applications, offering pulse or toggle functionality and adjustable hold time to meet a variety of access control needs.

Operating on a 433 MHz frequency, the receiver is compatible with the BEA 10TD433PB3V digital transmitter and supports up to 100 programmed transmitters per unit. With an input voltage of 12–24V AC/DC and a small footprint (3” × 2” × 1”), the 10RD433 is ideal for ADA-compliant doors, vestibules, and institutional entry systems.

Product Highlights:

• Item Number: 10RD433

• 433 MHz digital receiver for wireless push plate applications

• Compatible with BEA 10TD433PB3V transmitter

• Works with BEA Panther Series wireless push plates:

  • 10EMR6, 10EMR61, 10EMS475, 10EMS4751, 10EMR475, 10EMR4751, 10EMS475L, 10EMR475L, 10EMR6L

• Integral “learn” buttons for vestibule sequencing

• Pulse/toggle functionality with adjustable hold time

• Compact size: 3” × 2” × 1”

• Supports up to 100 transmitters per receiver

Technical Information:

• Frequency: 433 MHz

• Emitted Power: –28.7 dBm (TX)

• Power Consumption: 3 mA (TX), 30 mA (RX)

• Input Voltage: 12–24 VAC/DC

• Contact Rating:

  • 1.0 A @ 30 VDC

  • 0.5 A @ 125 VAC

  • 0.3 A @ 60 VDC

• Operating Temperature: 14°F to 131°F (–10°C to 55°C)

• Max Range:

  • Clear line of sight: 100 ft

  • Through building: 10–20 ft

• LEDs:

  • Red: Receiver Learn

  • Blue: Relay Activation

• Certifications: FCC, IC

Dimensions:

• Receiver: 2.75” × 2.125” × 1”

• Transmitter (for reference): 2.75” × 1.375” × 0.56”
