BEA 10PSMDR2024 100 240 VAC or 24 VDC output power supply

SKU:: 10PSMDR2024

MSRP: $83.60

$76.00

(You Save $7.60)

Usually Ships 4 to 7 Business Days

Current Stock:

Quantity:

Adding to cart… The item has been added

UPC:
brand-name:: BEA
brand-url:: /brand/bea/
atc-product:: LZR-H100
atc-product:: 10LZE-i30
availability:: available

Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Product Description
Related Products
Product Manual

The BEA 10PSMDR2024 20W Single Output Industrial DIN Rail Power Supply features Universal AC input and is intended for use on DIN rail TS-35/7.5 or 15. Free air convection protects internals from heat and the device is NEC class 2/LPS compliant. The MDR power supply comes with a three year warranty and is protected against short circuits, overloads, and over voltage.

Product Highlights

Universal AC input/Full range
Protections: Short circuit/Overload/Over Voltage
Free air convection cooling
Designed for installation on DIN rail TS-35/7.5 or 15
NEC class 2/LPS compliant
Built in DC OK active signal
LED indicator for power on
No load power consumption less than 0.75W
100% full load burn-in test
3 years warranty

Compatibility:

LZR-I30
LZR-H100
LZR-S600

Product Specs:

DC Voltage: 24V
Rated Currency: 1A
Current Range 0: 1A
Rated Power: 24W
Ripple & Noise: 150mVp-p
Voltage Tolerance: +/-1.0%
Line Regulation: +/-1.0%
Load Regulation: +/-1.0%
Setup, Rise Time: 500ms/230VAC, 1000ms 30ms/115VAC at full load
Hold Up Time: 50ms/230VAC, 20ms/115VAC at full load
Voltage Range: 85 ~ 264VAC, 120 - 370VDC
Frequency Range: 47 ~ 63Hz
Efficiency: 84%
AC Current: 0.55A/115VAC, 0.35A/230VAC
Inrush Current: COLD START 20A/115VAC, 40A/230VAC
Leakage Current: <1mA/240VAC
Overload: 105% ~ 160% rated input power
Overload Protection Type: Constant current limiting, recovers automatically after fault condition is removed
Over Voltage: 27.6 ~ 32.4V
Over Voltage Protection Type: Shut down o/p voltage, re-power on to recovers
DC OK Active Signal: 18 ~ 27V/20mA
Working Temp: -20 ~ +70°C (refer to output load derating curve)
Working Humidity: 20 ~ 90% RH non-condensing
Storage Temp. Humidity: -40 ~ +85°C, 10 ~ 95% RH
Vibration: Component: 10 ~ 500Hz, 2G 10min./1cycle, 60 min. each along x, y, z axes; Mounting: Compliance to IEC60068-2-6
Temp. Coefficient: +/-0.03%°C
Withstand Voltage: I/P-O/P: 3KVAC, I/P-F/G:1.5KVAC, O/P-FG:0.5KVAC
Isolation Resistance: I/P-O/P, I/P-FG, OP/FG:100M Ohms/500 VDC
EMI Conduction and Radiation: Compliance to EN55011, EN55022 (CISPR22), EN61000-6-1, EN61204-3, light industry level, criteria AC
MTBF: 236.9K hrs min. MIL-HDBK-217F
