BEA

Micro-Processed Lock-Out Relay Module 10LO21 by BEA

SKU:
10LO21
MSRP: $69.03
$62.75
(You save $6.28 )
  • Usually Ships 4 to 7 Business Days
availability:
available
Adding to cart… The item has been added
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

The BEA 10LO21 Lock-Out Module is a micro-processed control module designed for swing door applications using BEA’s Bodyguard or DK12 overhead presence sensors. It locks out header-mounted safety sensors during the door’s closing cycle by monitoring motor voltage to determine door position. The 10LO21 communicates this position data to the sensors and includes an optional safety beam input to override the inhibit signal if the beam path is blocked, ensuring enhanced safety during operation.

Product Highlights:

  • Item Number: 10LO21

  • Micro-processed lock-out module for swing doors

  • Compatible with BEA Bodyguard and DK12 sensors

  • Locks out header-mounted sensors during closing

  • Reads motor voltage to determine door position

  • Sends position data to sensors via data lines

  • Safety beam input cancels inhibit signal when beam is blocked

  • Triggers safety signal to door control if obstruction detected

Technical Specifications:

  • Power supply: 12–24V AC / 15–24V DC

  • Operating frequency: 4 MHz microprocessor

  • Power consumption: 10 mA (rest), 50 mA max

  • Output: 2 × SPST relays

  • Max relay voltage: 60V DC / 120V AC

  • Max relay current: 2A DC / 0.5A AC
